hi speed test board

Click to EnlargeThis is a high speed test board with a BGA socket with pogo pin outer array and a quad jumper array.



microwave microstrip

Click to EnlargeThis is a test board made for a microwave fixture with microstrip traces in a coplaner waveguide. Equal length traces with SMA connectors at equal spacing.



another hi speed test board

Click to EnlargeThis is a high speed test board with a BGA socket with pogo pin outer array and a quad jumper array.
